| SR20 1200 Turbo/Steering box clearance
 AFRacer  Misc  2004/5/15 9:21  Tell a friend
 3084  0  0.00 (0 votes)
| Another picture of the clearance between the stock turbo/outlet pipe and the steering box on a LHD 1200. Keep in mind the engine will actually sit higher once the mounts are done, resulting in even more clearance than you see here. |
|
| SR20 1200 engine mount
AFRacer Engine 2004/5/15 9:18 Tell a friend
3947 3 0.00 (0 votes)
| The stock 1200 mounts are in place on the crossmember and you can see where the SR20 mount is, kinda inside of it....of course the engine isn't in it's proper position yet, but real close. |
|
| SR20 1200 Firewall clearance
AFRacer Engine 2004/5/15 9:14 Tell a friend
3698 0 0.00 (0 votes)
| The is the right rear side of the engine to show you how much room you have to work with front/back. All of these pictures were taken with the engine in the same place. It could actually sit back a little further, about an inch or so. |
|
| SR20 1200 Front Clearance
AFRacer Engine 2004/5/15 9:12 Tell a friend
3946 0 0.00 (0 votes)
| This is using the 180SX radiator, stock radiator support cut away, and the engine could actually go back probably another inch at least. There's plenty of room to run a thin electric fan in there! |
|
| SR20 1200 rear engine shot
AFRacer Misc 2004/5/15 9:10 Tell a friend
2933 0 0.00 (0 votes)
| Here's a pic from behind the engine in a automatic tunneled 1200. The coolant lines running behind the engine should be run elsewhere to allow more space behind the engine. Also the brake and fuel lines need to be redone from at least half way back so they're not inside the tranny tunnel |
|
| SR20 1200 Outlet pipe exit location
AFRacer Engine 2004/5/15 9:07 Tell a friend
3652 0 0.00 (0 votes)
| Here's where the stock outlet pipe on the SR20 exits beneath the car...may even be able to use the SR20 downpipe too now!! |
|
| Outlet pipe SR20 LHD 1200
AFRacer Engine 2004/5/15 9:04 Tell a friend
3918 0 0.00 (0 votes)
| Stock outlet pipe and turbo fits fine in LHD 1200 coupe with plenty of room! |
|
| Left side of SR20 in 1200
AFRacer Engine 2004/5/15 8:58 Tell a friend
5934 5 0.00 (0 votes)
| The most wondered about area on a SR20 powered LHD car, lots of clearance with stock outlet pipe, turbo, and stock turbo location |
|
| Front View SR20
AFRacer Body and Interiors 2004/5/15 8:56 Tell a friend
9553 0 0.00 (0 votes)
| Front view of the car, still needs the intercooler |
|
| SR20 Inside
AFRacer Engine 2004/5/15 8:55 Tell a friend
4604 5 0.00 (0 votes)
|
