Brake caliper upclose
Brake caliper upclosePopular
SubmitterkululadotgroenMore Photos from kululadotgroen   Last Update2007/2/8 0:44    Tell a friendTell a friend
Hits2501  Comments7    0.00 (0 votes)0.00 (0 votes)
The make is Girlock, I don't know if they are a local make, but they do look substantial. I will upgrade the brakes even more in the future, when budget allows. Thought that the newer 1400 bakkie's struts were a logical step in between, as a prerequisite for further upgrades. I don't feel comfortable with fitting different struts altogether...

Also I'm sure one can make a set of Golf MK1 calipers and vented disks fit in here without so much trouble...

[<   Previous  3385  3386  3387  3388  3389  3390  3391  Next   >]

The comments are owned by the poster. We aren't responsible for their content.

Poster Thread
Dodgeman
Posted: 2007/2/8 1:47  Updated: 2007/2/8 1:47
No life (a.k.a. DattoMaster)
Joined: 2003/6/27
From: Southern Tablelands N.S.W. Australia
Posts: 8287
 Re: Brake caliper upclose
Girlock is the product of a marriage between Girling & Lockheed, both of which were international brake component manufacturers.

Interestingly, the founder of Lockheed was one of two brothers who went into two different, but newly emerging businesses. The original family name was actually "Loughead" & both re-spelled their names to make it easier to read/pronounce.

One brother went into the automotive sphere with brakes.


The other brother built airplanes, including these, the most beautifull airliner ever built.
Yes, I'm told that they had Lockheed brakes.


Poster Thread
TnPshow
Posted: 2007/2/8 2:09  Updated: 2007/2/8 2:09
No life (a.k.a. DattoMaster)
Joined: 2002/8/22
From: Adelaide, SA
Posts: 1991
 Re: Brake caliper upclose
What setup does the Bakkie use? I take it that it's an improvement to the early 1200 coupe type brakes my 94 ute has?

Edit - whoops I meant 84 ute

Poster Thread
kululadotgroen
Posted: 2007/2/8 3:09  Updated: 2007/2/8 3:09
No life (a.k.a. DattoMaster)
Joined: 2006/7/12
From: Cape Town ZA
Posts: 1054
 Re: Brake caliper upclose
Quote:
What setup does the Bakkie use? I take it that it's an improvement to the early 1200 coupe type brakes my 94 ute has?


It uses the Girlock one posted above. It's a huge improvement, the disk is much thicker, and the pad contact area is probably more than twice as large, plus the calipers are far more meatier than the standard 1200 ones.

I'm not sure when your ute's switched over to the bigger/better brakes, if they ever did, but I think our bakkies switched over directly from drums to these ones. The cars had disks long before the bakkies. I saw a 85' 1200 bakkie for sale the other day, and it still had drums, my car is far older than that and it had disks...

Unfortunately I dropped the old struts of at the wreckers before taking comparative pics, but will try to get some when I go by there again. But as a reference, the old pads had a contact area about the size of a match box, while the new ones were twice + bigger.

Poster Thread
beattie
Posted: 2007/2/8 3:50  Updated: 2007/2/8 3:50
No life (a.k.a. DattoMaster)
Joined: 2005/10/16
From: Perth WA
Posts: 2134
 Re: Brake caliper upclose
Those look like 180B calipers. The matchbox sized pad ones sound like those poxy opposing piston type used on B310's. I dont think AUS delivered utes ever had disks factory

Poster Thread
kululadotgroen
Posted: 2007/2/8 4:56  Updated: 2007/2/8 4:56
No life (a.k.a. DattoMaster)
Joined: 2006/7/12
From: Cape Town ZA
Posts: 1054
 Re: Brake caliper upclose
Quote:
Those look like 180B calipers. The matchbox sized pad ones sound like those poxy opposing piston type used on B310's


They might be, but I'm only now becoming familiar with Datsun brakes and stuff, I used to only fiddle with my VW's(I don't own one anymore). Also the old calipers sat behind the disks, and the new ones in front of the disks. This should help with heat dissipation. The older ones looked like they were made from 10mm steel plate bent to shape, and I seem to remember that they had two pistons...

Poster Thread
1200GXman
Posted: 2007/2/8 5:40  Updated: 2007/2/8 5:40
No life (a.k.a. DattoMaster)
Joined: 2003/11/28
From: South Africa, Bloemfontein
Posts: 1469
 Re: Brake caliper upclose
Hey, these look the same as what I currently have on my car.

I also upgraded to the 2005 model bakkie's front struts and calipers after 2 or 3 times that brake fade almost let me end up in hospital.
As kulula said, these calipers as definately better in that they have bigger brakepads and are now at the front of the strut and not the back like the old GX ones.
The disc's have a brake area of 460mm and a thickness of 14mm.
My original GX discs was about 3mm larger brake area and 0.8mm thick because I think it was overskimmed. GX discs are no longer available here in South Africa. The bakkie's one's are like R60 (south african rand) at any parts store. Cheap a$$.
I will test again soon to see if brake fade still occurs. This time in a safer environment where I can afford a mistake or two.

Poster Thread
dattoman_1000
Posted: 2007/2/8 15:44  Updated: 2007/2/8 15:44
No life (a.k.a. DattoMaster)
Joined: 2002/8/11
From: Perth
Posts: 2689
 Re: Brake caliper upclose
PBR bought out the Girlock brake business in about 1983 or so
Everything was then branded PBR in Australia but export products still carry the Girlock name in some markets
Seth Efrika being one of them
